Bathroom transfers are often some of the most difficult transfers caregivers perform at home. Bathrooms are usually smaller than bedrooms, contain hard surfaces, have limited maneuvering space, and may include obstacles such as toilets, vanities, shower doors, grab bars, and narrow doorways.
The right patient lift can make bathroom transfers more controlled and reduce the amount of manual lifting required from the caregiver. The most important first step is choosing the correct type of lift for the patient's mobility level.
Start With the Patient's Weight-Bearing Ability
Before choosing a lift for bathroom transfers, determine whether the patient can safely bear some weight through the legs and participate in standing.
In general:
- A sit-to-stand lift may be appropriate when the patient can bear some weight, maintain sufficient trunk control, and participate in the transfer.
- A full-body passive lift is generally the more appropriate category when the patient cannot safely stand or support their own weight.
Joerns makes the same basic distinction between active sit-to-stand lifts and passive full-body lifts.
Best Hoyer Lift for Bathroom Transfers When the Patient Can Stand With Assistance
For patients who can participate in standing, the Hoyer Journey Sit-to-Stand Lift is one of the strongest Hoyer options for bathroom transfers.
The Journey is an ultra-compact powered stand-aid with a folding design, adjustable sling attachment cradle, adjustable kneepad, and a relatively small footprint.
Joerns specifically designed the Journey for maneuverability in confined spaces.
Why the Hoyer Journey Works Well in Bathrooms
- Compact overall footprint
- 27-inch external width with the legs closed
- 38.2-inch external width with the legs open
- 45.1-inch turning radius
- Powered sit-to-stand assistance
- Adjustable kneepad
- Adjustable sling attachment cradle
- Folding design for storage or transportation
These dimensions can make the Journey easier to position around toilets, commodes, wheelchairs, and other bathroom fixtures than many larger full-body lifts.
Journey Toileting Slings
The Journey uses specialized active-lift sling systems rather than standard full-body passive slings.
Joerns identifies Standing and Transport sling configurations for use with the Journey.
The Transport Sling can provide additional transfer support and may be especially useful for appropriate toileting transfers.
Sling selection should consider the patient's:
- Weight
- Height
- Weight-bearing ability
- Trunk control
- Transfer type
- Required level of support
- Sling size
- Safe working load
When a Sit-to-Stand Lift Is Not Appropriate
A sit-to-stand lift should not be used simply because it is smaller or easier to maneuver.
If the patient cannot safely bear weight, cannot participate in standing, has insufficient trunk control, or requires complete body support, a passive full-body lift may be the more appropriate choice.
Best Hoyer Lift for Bathroom Transfers When Full-Body Support Is Needed
For patients who require complete lifting assistance, the Hoyer Advance-E 340 is one of the most practical Hoyer options for home bathroom transfers.
The Advance is a passive full-body electric lift with lightweight aluminum construction and a no-tools folding design.
Joerns also designed it with tapered swan-neck-style legs that help the lift move closer to large chairs, wheelchairs, and bulky commodes.
Why the Advance-E Works Well for Home Bathrooms
- Full-body passive lifting
- 341 lb safe working load
- Lightweight aluminum construction
- No-tools folding design
- Compact storage
- Tapered leg design
- Floor-transfer capability
- Designed for use around wheelchairs and commodes
Advance-E Bathroom Clearance
Joerns currently lists the Advance at approximately:
- 26.3 inches external width with the legs closed
- 42.5 inches external width with the legs open
- 51.2 inches maximum overall length
- 4.5 inches overall leg height
Those measurements are important because the lift may need to pass through a doorway and then open around the toilet, commode, wheelchair, or transfer surface.
Measure the Bathroom Before Choosing a Lift
Do not choose a bathroom lift based only on weight capacity.
Measure:
- The actual clear doorway opening
- The width of hallways leading to the bathroom
- Space beside and in front of the toilet
- Distance between the toilet and vanity
- Turning space inside the bathroom
- Clearance around grab bars
- Clearance around shower doors
- Space required for the caregiver
- Space required for the wheelchair or commode
Doorway Width Is Not the Only Measurement That Matters
A lift may fit through the bathroom doorway but still be difficult to use once it is inside.
The caregiver needs enough room to:
- Position the lift correctly
- Open the base when required
- Attach and remove the sling
- Move around the patient
- Access the toilet or commode
- Turn the lift safely
Always evaluate the entire transfer path, not just the doorway.
Keep the Floor Dry
Bathroom floors can become slippery from water, condensation, or cleaning products.
Before a transfer:
- Dry wet areas.
- Remove loose bath mats and rugs from the travel path.
- Clear cords and other obstacles.
- Make sure the lift casters can move freely.
Prepare the Toilet or Commode Before the Transfer
Prepare the destination before raising the patient.
Depending on the transfer, this may include:
- Positioning a commode correctly
- Opening or removing wheelchair footrests
- Moving unnecessary furniture
- Ensuring clothing can be managed safely
- Making hygiene supplies accessible
Avoid trying to reorganize the bathroom while the patient is already suspended or standing in the lift.
Lock the Destination Equipment
Wheelchairs, commode chairs, and other wheeled destination surfaces should be secured according to their manufacturer instructions before the patient is transferred onto them.
Do not confuse wheelchair or commode brakes with the caster instructions for the patient lift itself. Lift-brake guidance can differ by Hoyer model and by transfer type.
Lift Caster Brakes Are Model-Specific
One of the most important lessons from the Hoyer manuals is that rear caster brake instructions are not identical across every model and every transfer.
Do not automatically lock the patient-lift casters just because the transfer takes place in a bathroom.
Follow the current manufacturer manual for the specific Hoyer model and transfer being performed.
Select the Correct Sling
The sling must match both the patient and the lift.
Consider:
- Loop-style vs clip-style attachment
- Patient body measurements
- Patient weight
- Trunk and head support needs
- Toileting access requirements
- Safe working load
- Whether the lift is active or passive
Use our Hoyer Sling Compatibility Chart before ordering.
You can also use our Hoyer Sling Size & Compatibility Finder for additional sizing guidance.
Journey vs Advance-E for Bathroom Transfers
| Feature | Hoyer Journey | Hoyer Advance-E 340 |
| Lift Type | Active sit-to-stand | Passive full-body |
| Patient Participation | Required | Not required for standing |
| Safe Working Load | 341 lb | 341 lb |
| Closed External Width | 27 in | 26.3 in |
| Folding Design | Yes | Yes |
| Best Fit | Patient can participate in standing | Patient requires complete full-body lifting assistance |
Other Hoyer Options for Bathroom Transfers
The Journey and Advance are not the only options.
Depending on the patient's needs, you may also consider:
- Higher-capacity powered sit-to-stand → Hoyer Elevate
- Manual active transfer device → Hoyer Up
- 400 lb electric full-body lift → Hoyer HPL402
- 450 lb electric full-body lift → Hoyer HPL450
- 500 lb professional full-body lift → Hoyer Presence Pro 500
Bathroom Transfer Checklist
- Confirm the patient is appropriate for the selected lift type.
- Inspect the lift before use.
- Inspect the sling before use.
- Verify sling compatibility and safe working load.
- Dry the bathroom floor.
- Remove rugs and obstacles.
- Prepare the toilet, commode, or destination surface.
- Secure wheeled destination equipment as appropriate.
- Follow the specific Hoyer model's caster instructions.
- Keep the transfer path clear.
- Move slowly and communicate with the patient throughout the transfer.
Need Help Choosing a Hoyer Lift for Bathroom Transfers?
Call 877-33-HOYER or email support@myhoyerlift.com with the patient's height, weight, weight-bearing ability, bathroom doorway width, and primary transfer needs. We can help compare the Hoyer Journey, Hoyer Advance-E 340, and other Hoyer options for the space.
