Hoyer Elevate 440 lb Specs, Dimensions & Features Guide

Hoyer Elevate 440 lb Specs, Dimensions & Features Guide

The Hoyer Elevate is a powered active sit-to-stand lift designed for patients who can bear some weight and participate in standing transfers.

With a 440 lb safe working load, powered lifting, powered base adjustment, Hoyer Smart Monitor technology, an adjustable kneepad, removable angled foot tray, and optional integrated scale, the Elevate is the higher-capacity powered stand-aid in the current Hoyer lineup.

Hoyer Elevate Key Specifications

Safe Working Load 440 lb / 200 kg
Lift Type Powered active sit-to-stand lift
Maximum Overall Length 43.3 in / 1100 mm
Minimum Overall Length 41.0 in / 1040 mm
Maximum Overall Height 65.5 in / 1665 mm
Minimum Overall Height 48.4 in / 1230 mm
Maximum Height to Attachment Point 64.7 in / 1644 mm
Minimum Height to Attachment Point 39.2 in / 995 mm
Turning Radius 48.2 in / 1225 mm
Legs Open - External Width 39.1 in / 995 mm
Legs Open - Internal Width 34.3 in / 870 mm
Legs Closed - External Width 24.8 in / 630 mm
Legs Closed - Internal Width 20.0 in / 510 mm
Widest Point Between Support Handles 29.0 in / 738 mm
Overall Leg Height 4.7 in / 120 mm
Ground Clearance 1.4 in / 35 mm
Front Twin Casters 4.0 in / 100 mm
Rear Braked Casters 4.0 in / 100 mm
Total Weight Without Scale 135.6 lb / 61.5 kg
Total Weight With Scale 136.7 lb / 62 kg
Foot Tray Weight 23.1 lb / 10.5 kg

Joerns notes that manufacturing tolerances apply to published dimensions.

What Type of Lift Is the Hoyer Elevate?

The Elevate is an active sit-to-stand lift.

Unlike a passive full-body patient lift, the Elevate is designed for patients who can participate in the standing process and have an appropriate degree of weight-bearing ability.

The powered lifting system assists the patient from a seated position toward standing while a specialized stand-aid sling, kneepad, and foot tray provide support.

440 lb Safe Working Load

The Hoyer Elevate has a safe working load of 440 lb / 200 kg.

This gives it greater lifting capacity than the Hoyer Journey, which has a safe working load of 341 lb / 155 kg.

Never exceed the safe working load of the lift, sling, scale, or any other component used during the transfer.

Who Is the Hoyer Elevate Designed For?

The Elevate may be appropriate for patients who:

  • Can bear some weight through the legs
  • Can participate in standing
  • Have sufficient trunk control for the selected sling
  • Can follow transfer instructions
  • Need powered assistance moving from sitting toward standing
  • Need assistance with appropriate chair, wheelchair, bedside, or toileting transfers

When Is an Active Lift Not Appropriate?

The Elevate is not a passive full-body patient lift.

If the patient cannot safely bear weight or participate in standing, a passive Hoyer lift such as the Hoyer Advance-E 340 or Hoyer Presence Pro 500 may be the more appropriate equipment category.

Powered Lifting

The Elevate uses an electric actuator to assist the patient through the sit-to-stand movement.

The caregiver operates the lift using the hand control while the patient is supported by the appropriate stand-aid sling, kneepad, and foot tray.

The powered system provides controlled raising and lowering without requiring the caregiver to manually lift the patient's body weight.

Powered Base Adjustment

The Elevate also uses powered leg adjustment.

The base can be opened and closed electrically to help position the lift around chairs, wheelchairs, commodes, and other seated transfer surfaces.

This is an important difference from stand-aids that require manual base adjustment.

How Wide Is the Hoyer Elevate?

With the base closed, the Elevate measures approximately:

  • 24.8 inches external width
  • 20.0 inches internal width

With the base fully open, it measures approximately:

  • 39.1 inches external width
  • 34.3 inches internal width

These measurements are particularly important when checking doorway clearance and positioning around wheelchairs or other seating.

Will the Elevate Fit Through a Doorway?

The published closed external base width is approximately 24.8 inches.

Do not assume that a nominal doorway width provides the same usable clearance.

Measure the actual narrowest opening and account for:

  • Door trim
  • Hinges
  • Door swing
  • Thresholds
  • Caster orientation
  • Nearby furniture

Turning Radius

Joerns lists the Elevate's turning radius at approximately 48.2 inches.

Turning radius matters because a lift may physically pass through a doorway but still require substantially more room to turn and position around a chair, toilet, wheelchair, or bed.

Attachment Height Range

Joerns lists the Elevate's sling attachment range at:

  • 39.2 inches minimum
  • 64.7 inches maximum

This range is designed around active sit-to-stand transfers rather than floor-level passive lifting.

One-Hand Adjustable Kneepad

The Elevate includes a one-hand adjustable kneepad with a wide range of positioning settings.

The kneepad can be adjusted to accommodate different patient heights and lower-leg dimensions.

Correct kneepad positioning is important for both comfort and stability during an active transfer.

Angled Removable Foot Tray

The Elevate includes an angled removable foot tray.

During a standard sit-to-stand transfer, the patient's feet are positioned on the foot tray while the knees are supported against the kneepad.

The foot tray can also be removed when appropriate for restorative standing or supervised mobility activities.

Restorative Standing & Mobility

Joerns designed the Elevate with restorative-care applications in mind.

Removing the foot tray allows an appropriately assessed patient to place their feet directly on the floor while remaining supported by the active-lift system.

Any standing or mobility activity should be performed according to the patient's care plan and after an appropriate risk assessment.

Smart Monitor Technology

The Elevate includes Hoyer Smart Monitor technology as standard equipment.

The Smart Monitor provides information related to lift usage and maintenance and helps caregivers and service personnel monitor the condition and service requirements of the lift.

Joerns specifically highlights lift-count information and service reminders as key Smart Monitor features.

Optional Integrated Digital Scale

The Elevate can be configured either with or without a digital patient scale.

The optional scale is integrated into the lift and provides a digital display for weighing an appropriate patient during the transfer process.

The scale does not increase the Elevate's 440 lb safe working load.

Elevate Weight With & Without the Scale

Joerns lists the total Elevate weight at approximately:

  • 135.6 lb without the scale
  • 136.7 lb with the scale

This makes the Elevate substantially heavier than the compact Hoyer Journey and reflects its larger structure, powered base, higher safe working load, and professional feature set.

Intuitive Push Pad

The Elevate includes a rear push pad designed to help the caregiver initiate movement.

Joerns identifies this as a caregiver-assistance feature intended to reduce the initial force required to begin moving the lift.

The lift should still be maneuvered using its designated caregiver contact points and according to the manufacturer instructions.

Elevate Sling System

The Elevate uses specialized active-lift slings rather than standard passive floor-lift slings.

A compatible option available from My Hoyer Lift is the Hoyer Deluxe Stand-Aid Sling.

This is a loop-style active sling designed for powered Hoyer sit-to-stand lifts including the Elevate and Journey.

It is not a full-body passive sling.

Choosing an Elevate Sling

Sling selection should account for:

  • Patient weight
  • Patient height
  • Weight-bearing ability
  • Trunk control
  • Transfer type
  • Required level of support
  • Sling attachment method
  • Sling size
  • Sling safe working load

Do not assume that a sling used with an Advance, Presence, HPL450, HPL700, or another passive Hoyer lift will fit the Elevate.

Use our Hoyer Sling Compatibility Chart before ordering.

Elevate vs Hoyer Journey

The Hoyer Journey and Elevate are both powered active lifts, but they prioritize different features.

The Journey has a 341 lb safe working load and emphasizes compact size, folding storage, and portability.

The Elevate increases safe working load to 440 lb and adds powered base adjustment, a larger professional platform, and an optional integrated scale.

Elevate vs Hoyer Up

The Hoyer Up is a non-powered active transfer device.

The Up relies much more heavily on the patient's ability to actively pull to stand.

The Elevate provides powered lifting assistance and is therefore a fundamentally different type of active transfer device.

Elevate vs Passive Hoyer Lift

The most important distinction is not capacity or dimensions. It is whether the patient is appropriate for an active sit-to-stand transfer.

The Elevate is designed for patient participation.

A passive lift supports the patient's full body weight in a full-body sling and is used when active standing participation is not appropriate.

Is the Hoyer Elevate a Floor Lift?

No. The Elevate is an active sit-to-stand lift designed around seated-to-standing transfers.

Joerns lists the minimum sling attachment height at approximately 39.2 inches, which reflects its active-lift geometry.

A passive full-body floor lift should be considered when floor-level recovery or full-body suspension is required.

Does the Elevate Fold?

The Elevate is not designed as a folding portable lift.

If no-tools folding storage and transportation are major requirements, the Hoyer Journey is the more compact powered stand-aid in the current Hoyer lineup.

Measure Before Ordering

Before ordering an Elevate, measure:

  • The narrowest doorway along the travel path
  • Hallway width
  • Bathroom clearance
  • Space around the toilet or commode
  • Clearance around chairs and wheelchairs
  • Available turning space
  • Clearance underneath furniture where the base legs need to travel
  • Storage space

Hoyer Elevate Specifications at a Glance

  • 440 lb / 200 kg safe working load
  • Powered sit-to-stand lifting
  • Powered base adjustment
  • 43.3-inch maximum overall length
  • 24.8-inch closed external base width
  • 39.1-inch open external base width
  • 39.2-to-64.7-inch attachment range
  • 48.2-inch turning radius
  • 4.7-inch leg height
  • 1.4-inch ground clearance
  • 4-inch front twin casters
  • 4-inch rear braked casters
  • Smart Monitor technology
  • One-hand adjustable kneepad
  • Angled removable foot tray
  • Optional integrated digital scale

Related Hoyer Elevate Resources

Need Help With Your Hoyer Elevate?

Call 877-33-HOYER or email support@myhoyerlift.com for help identifying compatible Hoyer Elevate slings, scale options, batteries, chargers, replacement parts, accessories, or Joerns manufacturer resources for your Hoyer Elevate.
