Proper battery care, powered-base inspection, Smart Monitor checks, cleaning, and preventive maintenance help keep the Hoyer HPL700 ready for high-capacity patient transfers. Joerns provides specific charging, inspection, and maintenance instructions for the HPL700 that should be followed rather than relying on generic patient-lift advice.
HPL700 Battery System
The Hoyer HPL700 is supplied with two detachable rechargeable battery packs and an off-board desktop charger.
The lift uses one battery pack at a time. The second pack can be kept charged and ready so caregivers can exchange batteries when needed and reduce downtime.
Joerns recommends keeping the batteries fully charged whenever possible.
How Long Does the HPL700 Battery Take to Charge?
Joerns states that a full charge takes approximately four hours.
Charging is automatic:
- Green light – mains power is on
- Yellow light – the battery is charging
- Yellow light off – the battery is fully charged
Joerns recommends charging the battery immediately when the lift is first received.
How to Charge the HPL700
- Remove the battery pack from the lift by releasing the latch at the top of the pack.
- Fit the battery pack securely onto the off-board charging unit.
- Plug the charger into an appropriate electrical outlet and switch the power on.
- Allow the automatic charging cycle to complete.
- When the yellow charging light turns off, disconnect the charger from power.
- Remove the battery pack from the charger.
- Reinstall the battery on the HPL700 and make sure the retaining latch clicks securely into place.
Can You Leave the Battery Charging Overnight?
Yes. Joerns recommends keeping the batteries fully charged and states that a battery may be placed on charge whenever it is not in use.
If convenient, the battery can be charged every night. The charger is designed to prevent overcharging even when the battery remains connected for an extended period.
Do Not Run the Battery Completely Flat
Joerns specifically instructs users never to run HPL700 batteries completely flat.
If the audible low-battery warning sounds during a transfer, complete the lifting operation already in progress and place the battery on charge.
Joerns also recommends charging the battery as soon as the display shows the half-empty battery symbol to help avoid permanent battery damage.
Battery Storage
Do not store the HPL700 battery for long periods without regular charging.
Joerns also instructs users not to leave the battery pack connected to the charger when the charger itself is unplugged.
Before returning a stored lift to service, confirm that the battery is adequately charged and complete the normal pre-use inspection.
Important Charging Safety
- Do not open the battery, charger, hand control, or control box.
- Do not touch the battery or charger terminals.
- Do not disconnect the charger by pulling on the cable.
- Keep the charging cable positioned so it does not create a trip hazard.
- Do not leave the charger powered with no battery connected.
- Do not charge HPL700 batteries in a bathroom or shower room.
Powered Base
The HPL700 comes with a power-operated base.
The caregiver can open and close the lift legs using the hand control rather than manually spreading the base.
This is especially useful during higher-capacity transfers where reducing caregiver bending and forceful leg adjustment is important.
Powered Base Inspection
Before use, confirm that the base opens and closes correctly using the hand control.
Joerns recommends checking that the legs travel through their full inward and outward range.
Listen for unusual noise from the leg actuator and inspect visible actuator connections and cables for damage.
Do not force the base legs against furniture, walls, beds, or other obstructions.
Hoyer Smart Monitor
Current HPL700 models use Hoyer Smart Monitor technology to track lift usage and service information.
The Smart Monitor can record and display:
- Number of patient lift cycles
- Total work performed by the actuator
- Number of overload events
- Number of days since the last service interval
- Service reminders
- Battery status
The monitor uses an onboard LCD screen to display this information to caregivers and service personnel.
Three-Step Battery Indicator
The HPL700 Smart Monitor includes a three-step battery indicator.
When the display reaches the half-empty battery symbol, Joerns recommends placing the battery on charge as soon as possible.
Do not intentionally continue using the lift until the battery is completely discharged.
Overload Protection
The Smart Monitor records attempted lifts above the safe working load.
If an overload condition occurs, lower the boom, remove the excess load, and complete the normal safety checks before returning the lift to service.
The HPL700 has a safe working load of 700 lb. Never intentionally use overload protection as a method of testing patient weight.
Emergency Stop & Redundant Controls
The HPL700 control box includes an emergency stop button and redundant raise/lower controls.
Current Smart Monitor configurations also provide redundant controls for opening and closing the powered legs.
Caregivers should know the location and function of these controls before the lift is placed into regular service.
Daily / Before-Use HPL700 Checklist
Joerns strongly recommends the following checks daily and before using the lift:
- Make sure the lift moves freely on its casters.
- Confirm the spreader bar rotates and swings freely.
- Make sure the spreader bar is firmly attached to the boom.
- Confirm the mast is fully engaged and securely locked.
- Inspect sling hooks and side suspenders for excessive wear.
- Make sure the powered legs open and close correctly.
- Operate the hand control and confirm the boom raises and lowers properly.
- Confirm there is no low-battery warning.
- Test the emergency stop button.
- Inspect the sling for fraying, tears, cuts, or other damage.
Spreader Bar Inspection
The HPL700 uses a 6-point bariatric loop spreader bar for compatible Hoyer loop-style bariatric slings.
Inspect the spreader bar for:
- Freedom of rotation and swing
- Wear at the central pivot
- Secure attachment to the boom
- Damage or excessive wear at sling attachment points
Do not use the lift if the spreader bar or its attachment hardware appears damaged or insecure.
Quick-Release Pin Inspection
The spreader bar is secured using a quick-release pin.
Joerns specifically instructs users to confirm that the pin is fully inserted and securely locked before lifting.
Do not begin a transfer if the quick-release pin is not completely engaged.
Inspect the Sling Before Every Transfer
Joerns recommends checking slings regularly and particularly before use.
Inspect the sling for:
- Fraying
- Tears or cuts
- Damaged stitching
- Worn attachment loops
- Other signs of deterioration
Do not use a damaged sling.
The HPL700 6-point bariatric loop system is compatible with Hoyer bariatric loop-style sling families such as:
Use our Hoyer Sling Compatibility Chart before ordering a sling for the HPL700.
Boom & Mast Inspection
Inspect the boom-to-mast attachment and confirm that there is only minimal side movement.
Make sure the boom moves freely on its bearing.
Check the mast-locking device and confirm that the mast is fully engaged in the base socket.
Also inspect the lower actuator connection during routine maintenance.
Actuator Inspection
Joerns states that the lifting actuator generally requires no routine maintenance beyond checking for correct operation and listening for unusual noise.
Irregular movement, slow response, or unusual sounds should be evaluated before the lift is returned to service.
Hand Control Inspection
Make sure the hand control is plugged fully into the controller.
Test:
- Boom raise
- Boom lower
- Legs open
- Legs close
Inspect the hand-control cable and plug for visible damage.
Caster Inspection
Confirm that all casters are firmly attached to the lift legs.
Check for free caster rotation and free wheel movement.
Remove hair, thread, debris, or other material that could interfere with caster movement.
Base & Wheel Inspection
Joerns recommends checking that the HPL700 base is even and level with all four wheels contacting the floor.
Do not continue using the lift if the base appears twisted, uneven, damaged, or unstable.
Cleaning the HPL700
Joerns recommends cleaning the HPL700 with ordinary soap and water and/or an appropriate hard-surface disinfectant.
Avoid harsh chemical cleaners and abrasive products because they may damage the surface finish.
Avoid wetting electrical components, including the battery, control box, hand control connections, and actuator connections.
Lubrication
Joerns includes lubrication of designated pivot joints as part of annual maintenance.
Appropriate points can include:
- Mast and boom connections
- Pedal assembly where applicable
- Spreader-bar joint when required
- Other manufacturer-designated pivot points
Joerns specifies a light food-grade spray lubricant for appropriate pivot joints.
700 lb Safe Working Load
The HPL700 has a safe working load of 700 lb.
Never exceed the safe working load of the lift, sling, spreader bar, optional scale, or any other component in the transfer system.
The usable capacity of the complete transfer system is always limited by its lowest-rated component.
Annual Service
Joerns recommends daily checks plus a yearly service, inspection, and test.
Annual service should include inspection of:
- Spreader bar
- Boom
- Mast
- Lifting actuator
- Control box / Smart Monitor
- Batteries and electrical connections
- Powered leg adjustment
- Casters
- Base and wheels
- Slings
- Quick-release pin
- Hand control
- Hardware and fasteners
Structural repairs, electrical service, actuator repair, control-system work, and formal load testing should be performed by qualified service personnel or an authorized Hoyer service resource.
When to Stop Using the HPL700
Remove the lift from service and arrange inspection if you notice:
- A battery that will not maintain adequate charge
- Repeated low-battery warnings after proper charging
- Intermittent or unresponsive hand-control operation
- Powered legs that do not open or close correctly
- Unusual actuator noise or movement
- A Smart Monitor overload or persistent service warning
- A damaged or insecure spreader bar
- A loose or damaged mast or boom connection
- Casters that do not roll or swivel freely
- An uneven or damaged base
- A damaged sling or sling attachment
Genuine HPL700 Replacement Parts
Genuine Joerns HPL700 service parts include:
- Battery packs
- Desktop charger and stand
- Smart Monitor / control box
- Hand control
- Lifting actuator
- Leg actuator
- Front and rear casters
- Quick-release pin
- 6-point bariatric loop spreader bar
- Scale-equipped spreader-bar assemblies
Replacement parts should be verified for exact HPL700 compatibility before installation.
