How to Use the Hoyer Calibre 850 Safely – Bariatric Transfer Guide

The Hoyer Calibre is a heavy-duty bariatric patient lift designed for lifting and transferring patients up to 850 lb. Joerns specifies that the Calibre is intended for indoor use and must be operated by a minimum of two caregivers.

Preparation Checklist

• Ensure the battery is adequately charged before use.
• Clear a wide transfer path and allow sufficient room for the Calibre’s large powered base.
• Confirm that at least two caregivers are available to operate the lift.
• Select a properly sized bariatric sling that is compatible with the Calibre and appropriate for the patient.
• Inspect the sling for wear, fraying, or damage before use.
• Check that the lift is in proper working condition and that all wheels are in contact with the floor on a level surface.
• Explain the transfer process to the patient before beginning.

Standard Transfer Sequence

1. Use the powered leg adjustment to position the base around the chair, bed, or wheelchair as needed for the transfer.
2. Keep the casters free and the brakes released while lifting.
3. Apply the appropriate bariatric sling according to the sling instructions.
4. Attach the sling securely to the 6-point cradle.
5. Confirm that all sling attachment points are secure before lifting.
6. Raise the patient smoothly using the hand control.
7. Use the integrated scale when weighing is required, following the scale instructions supplied with the lift.
8. Move the lift carefully using the wide wrap-around push handle and with both caregivers coordinating the transfer.
9. Lower the patient in a controlled manner onto the destination surface.
10. Once the patient is safely supported, detach and remove the sling as appropriate.

Calibre Caster & Brake Safety

The Hoyer Calibre has two braked casters that may be used for parking. During patient lifting, Joerns instructs that the casters should remain free and unbraked. This allows the lift to move toward its center of gravity rather than causing the patient to swing toward the center of gravity.

Two-Caregiver Requirement

Joerns specifies that the Hoyer Calibre must be operated by a minimum of two caregivers. The Calibre is a large bariatric lift, and its wide wrap-around push handle is designed to allow multiple caregivers to assist with maneuvering.

850 lb Safe Working Load

The Hoyer Calibre has a safe working load of 850 lb (385 kg). Never exceed the safe working load of the lift or the safe working load of the sling being used.

Integrated Scale

The Calibre includes an integrated digital scale, allowing patient weight to be monitored without transferring the patient to a separate scale. Follow the scale operating instructions supplied with the lift when zeroing, weighing, and reading the display.

Calibre Sling System

The Hoyer Calibre uses a 6-point positioning cradle with loop-style sling attachment straps. Joerns identifies the Hoyer Bariatric Hammock Sling as suitable for use with the Calibre and rates it to a safe working load of 850 lb.

Sling selection should be based on the patient’s size, positioning needs, transfer requirements, and clinical assessment. Always confirm sling size, attachment compatibility, and safe working load before use.
