Choosing between the Hoyer Calibre 850, Hoyer Presence Pro 500, Hoyer Stature, and Hoyer Advance-E 340 depends on more than patient weight. These four lifts are designed around very different priorities: bariatric capacity, professional versatility, true vertical lifting, and portability.
The Advance-E is the smallest and most portable option. The Presence and Stature are both 500 lb professional lifts with different positioning advantages. The Calibre is the high-capacity bariatric model with an 850 lb safe working load and a standard integrated scale.
Quick Comparison
| Feature | Advance-E 340 | Presence Pro 500 | Stature | Calibre 850 |
| Safe Working Load | 341 lb | 500 lb | 500 lb | 850 lb |
| Lift Type | Passive full-body | Passive full-body | Passive full-body | Passive bariatric full-body |
| Powered Boom | Yes | Yes | Yes | Yes |
| Base Adjustment | Manual | Powered | Powered | Powered |
| Folding Design | Yes | No | No | No |
| Smart Monitor | No | Yes | Available with Smart Monitor control system | Yes |
| Scale | Optional accessory configuration | Optional | Optional | Standard |
| Primary Advantage | Portability & storage | Professional versatility | True vertical lifting | 850 lb bariatric capacity |
Hoyer Advance-E 340 – Best for Portability & Storage
The Hoyer Advance-E 340 is the most compact and portable lift in this comparison.
Joerns designed the Advance with lightweight aluminum construction and a no-tools folding system. It can stand upright while folded and can be transported in its folded configuration.
The Advance is a full-body passive lift and is capable of appropriate transfers from floor level to healthcare-bed height.
Why Choose the Advance-E?
- 341 lb safe working load
- Electric lifting
- Lightweight aluminum construction
- No-tools folding design
- Compact storage
- Designed for transportation
- Floor-transfer capability
- Angled legs for positioning around chairs, commodes, and wheelchairs
Advance-E Dimensions
Current Joerns specifications list the Advance at approximately:
- 51.2 inches maximum overall length
- 42.5 inches external width with the legs open
- 26.4 inches external width with the legs closed
- 73.2 inches maximum overall height
- 69.7 lb total weight
Its folded dimensions are approximately:
- 17.7 inches high
- 46.5 inches deep
- 21.7 inches wide
Who Is the Advance-E Best For?
The Advance is a strong option when the patient is within its safe working load and the lift needs to be stored, transported, or used in a smaller home environment.
It is not the right choice when higher patient capacity or professional powered-base features are required.
Hoyer Presence Pro 500 – Best All-Around Professional Option
The Hoyer Presence Pro 500 is a 500 lb professional passive lift designed to handle a wide range of patient-handling tasks.
It comes standard with powered leg adjustment and Smart Monitor technology and can lift residents from the floor as well as accommodate transfers to higher surfaces.
Why Choose the Presence?
- 500 lb safe working load
- Electric lifting
- Powered base
- Smart Monitor technology
- Floor-transfer capability
- Transfers to higher surfaces
- Optional scale
- Choice of sling attachment systems
Presence Sling System Flexibility
The Presence can be configured with either:
- A 6-point spreader bar for compatible Hoyer loop-style slings
- A 4-point positioning cradle for compatible Hoyer Comfort Securi3 clip-style slings
That flexibility is useful in professional environments where different patient positioning needs may require different sling systems.
Who Is the Presence Best For?
The Presence is a strong choice when 500 lb capacity is sufficient and you want a professional lift that balances capacity, powered leg adjustment, floor lifting, higher-surface transfers, and Smart Monitor functionality.
Hoyer Stature – Best for True Vertical Lifting
The Hoyer Stature also has a 500 lb safe working load, but its defining feature is true vertical lifting.
Joerns designed the Stature for more demanding and technical patient-handling situations where vertical positioning and a large lifting range are important.
It also comes with powered leg adjustment and supports both clip-style and loop-style sling configurations depending on the installed cradle or spreader bar.
Why Choose the Stature?
- 500 lb safe working load
- True vertical lifting path
- Powered base
- Floor-transfer capability
- Large lifting range
- Suitable for higher transfer surfaces
- 4-point clip-style cradle option
- 6-point loop-style spreader bar option
- Optional powered positioning cradle
- Optional patient scale
Stature Dimensions
Current Joerns specifications list the Stature at approximately:
- 54.7 inches maximum overall length
- 53.5 inches external width with the legs open
- 29.9 inches external width with the legs closed
- 83.8 inches maximum overall height
- 162 lb total weight
The Stature requires more room than the Presence or Advance, so doorway width and turning space should be measured carefully.
Who Is the Stature Best For?
The Stature may be the better 500 lb choice when vertical lifting geometry, technical positioning, larger transfer surfaces, or higher-surface transfers are more important than compact maneuverability.
Hoyer Calibre 850 – Best for High-Capacity Bariatric Transfers
The Hoyer Calibre 850 is in a different capacity class from the other three lifts.
It has an 850 lb safe working load and is specifically designed for heavier bariatric patients.
Joerns includes Smart Monitor technology, powered leg adjustment, articulated front casters, an extra-wide wrap-around caregiver handle, and a standard integrated patient scale.
Why Choose the Calibre?
- 850 lb safe working load
- Electric lifting
- Powered base
- Smart Monitor technology
- Integrated scale included as standard
- Extra-wide wrap-around caregiver handle
- Articulated front casters
- 6-point bariatric cradle
- Designed specifically for bariatric patient handling
Calibre Dimensions
Current Joerns product specifications list the Calibre at approximately:
- 64 inches maximum overall length
- 55.25 inches external width with the legs open
- 33.25 inches external width with the legs closed
- 37 inches maximum reach
The Calibre is substantially larger than the Advance, Presence, and many standard homecare lifts.
Who Is the Calibre Best For?
The Calibre should be considered when patient weight, body dimensions, or bariatric-care requirements exceed what standard 500 lb professional lifts can safely support.
Joerns also specifies a minimum of two caregivers for Calibre operation, which is another important difference from smaller homecare lifts.
Capacity Comparison
- Hoyer Advance-E 340 – 341 lb
- Hoyer Presence Pro 500 – 500 lb
- Hoyer Stature – 500 lb
- Hoyer Calibre – 850 lb
Capacity is important, but it should never be the only selection criterion.
Patient body dimensions, mobility, positioning needs, sling requirements, transfer surfaces, doorway width, available room, caregiver staffing, and the patient's care plan should also be considered.
Presence vs Stature – Which 500 lb Lift Should You Choose?
The Presence and Stature have the same 500 lb safe working load, but they are designed around different priorities.
Choose the Presence when you want a lighter, more versatile professional lift with Smart Monitor technology, powered legs, and a relatively manageable footprint.
Choose the Stature when true vertical lifting, a larger open base, and technical positioning around higher or wider transfer surfaces are more important.
Advance-E vs Presence
Choose the Advance when portability, folding storage, lower total weight, and transportation matter most and the patient is within its 341 lb safe working load.
Choose the Presence when you need higher 500 lb capacity, powered base adjustment, Smart Monitor technology, and a professional full-body lift that does not need to fold.
Advance-E vs Stature
The Advance is designed around portability.
The Stature is designed around professional vertical-lifting geometry and higher-capacity transfer capability.
These are very different lifts despite both being full-body passive patient lifts.
Presence vs Calibre
The Presence is rated to 500 lb and is substantially smaller and lighter.
The Calibre increases safe working load to 850 lb and adds bariatric-specific design features such as the wide wrap-around caregiver handle, articulated front casters, large bariatric cradle, and standard integrated scale.
Stature vs Calibre
Choose the Stature when 500 lb capacity is sufficient and true vertical lifting is the main priority.
Choose the Calibre when higher bariatric capacity, a standard integrated scale, and bariatric-specific maneuvering features are required.
Which Lift Is Best for a Small Home?
The Advance-E is the strongest option in this group when compact storage and portability are the priorities.
The Presence may also work in some home environments when professional features and 500 lb capacity are required.
The Stature and Calibre require considerably more room.
Which Lift Is Best for Higher Surfaces?
The Stature is specifically designed around true vertical lifting and demanding positioning requirements.
The Presence also supports transfers to higher surfaces and provides a long lifting range.
When higher transfer surfaces are a major consideration, compare the exact lift geometry, installed cradle or spreader bar, sling, and destination height before choosing.
Which Lift Is Best for Floor Transfers?
The Advance, Presence, and Stature are all designed to support appropriate floor-level transfers when used according to the manufacturer's instructions.
The Calibre is also a full-body passive lift designed for bariatric patient handling, but adequate floor space and caregiver access are especially important because of its larger size.
Which Lift Is Easiest to Store?
The Advance is the clear storage-focused choice because it folds without tools and can stand upright while folded.
The Presence, Stature, and Calibre are full-size mobile floor lifts rather than folding travel lifts.
Which Lift Has the Best Scale Setup?
The Calibre includes an integrated patient scale as standard equipment.
The Presence and Stature offer scale options.
The Advance can also be configured with an Advance-specific spreader bar with integrated weighing capability.
A scale never increases the safe working load of the lift.
Which Lift Requires the Most Room?
The Calibre has the largest bariatric footprint in this comparison.
Its approximately 33.25-inch closed external width and 55.25-inch open external width make doorway and room measurements especially important.
The Stature also requires significant room because its open external width is approximately 53.5 inches.
Sling Compatibility
Sling attachment systems differ across these four lifts.
The Advance uses compatible loop-style Hoyer slings with a 6-point spreader bar.
The Presence and Stature can use either compatible loop-style slings with 6-point spreader bars or Hoyer Comfort Securi3 clip-style slings with compatible 4-point positioning cradles.
The Calibre uses a large 6-point bariatric cradle and requires appropriately rated loop-style bariatric slings.
Do not assume a sling that fits one Hoyer lift will automatically fit another.
Use our Hoyer Sling Compatibility Chart before ordering.
Calibre Bariatric Sling
The current Joerns Calibre manual specifically identifies the Hoyer Bariatric Hammock Sling for the Calibre's 6-point cradle.
Sling safe working load, sizing, patient measurements, and transfer suitability must always be verified before use.
Which Hoyer Lift Should You Choose?
- Choose the Hoyer Advance-E 340 when portability, compact storage, and transportation are the main priorities and the patient is within its safe working load.
- Choose the Hoyer Presence Pro 500 when you want a versatile 500 lb professional lift with powered legs and Smart Monitor technology.
- Choose the Hoyer Stature when true vertical lifting and technical positioning are the primary requirements.
- Choose the Hoyer Calibre 850 when bariatric capacity up to 850 lb, integrated weighing, and heavy-duty caregiver-access features are required.
The final choice should consider patient weight, body dimensions, mobility, sling requirements, transfer surfaces, room dimensions, caregiver staffing, and the patient's overall care plan.
