HPL450 vs Advance-E vs HPL402 vs Presence – Which Electric Lift Should You Choose?

Aug 26, 2026

If you are comparing electric Hoyer patient lifts, four models cover a wide range of homecare and professional lifting needs: the Hoyer Advance-E 340, Hoyer HPL402, Hoyer HPL450, and Hoyer Presence Pro 500.

All four are full-body passive patient lifts, but they are designed around different priorities. The Advance emphasizes portability, the HPL402 provides straightforward powered homecare lifting, the HPL450 adds capacity and configuration flexibility, and the Presence provides a 500 lb capacity, powered base, Smart Monitor technology, and a long lifting range.

Hoyer Electric Lift Comparison at a Glance

Feature	Advance-E	HPL402	HPL450	Presence
Safe Working Load	341 lb / 155 kg	400 lb / 181 kg	450 lb / 204 kg	500 lb / 227 kg
Powered Boom	Yes	Yes	Yes	Yes
Base Operation	Manual	Manual adjustable U-base	Powered or foot-operated manual base	Powered
Folding Design	Yes	No	No	No
Floor Transfers	Yes	Yes	Full-body floor lift	Yes
Smart Monitor	No	No	No	Yes
Primary Advantage	Portability	400 lb electric homecare lifting	450 lb capacity and configuration flexibility	500 lb capacity and professional features

Hoyer Advance-E 340 – Best for Portability

The Hoyer Advance-E 340 is the most portable lift in this comparison.

Joerns designed the Advance with lightweight aluminum construction and a no-tools folding system. It can fold into a compact configuration for storage and transportation while still providing the lifting range needed for transfers from floor level to healthcare beds.

Its tapered swan-neck-style legs also help the lift approach large chairs, wheelchairs, and commodes.

Why Choose the Advance-E?

341 lb safe working load
Electric raising and lowering
Lightweight aluminum construction
No-tools folding design
Compact folded storage
Suitable for floor-level transfers
Tapered legs for positioning around furniture
Strong choice when the lift must be transported or stored frequently

Advance-E Size

Current Joerns specifications list the Advance at approximately 51.2 inches maximum overall length and 73.2 inches maximum overall height.

When folded, Joerns lists it at approximately 17.7 inches high, 46.5 inches deep, and 21.7 inches wide.

Those folded dimensions are one of the biggest differences between the Advance and the other three lifts in this comparison.

Hoyer HPL402 – Best for Straightforward 400 lb Electric Homecare Lifting

The Hoyer HPL402 increases capacity to 400 lb while retaining a traditional Hoyer Classic design.

It uses a battery-powered actuator with a manually adjustable U-base. Joerns reverse-mounts the actuator to provide additional knee clearance and includes protective leg guards and caster bumpers.

Why Choose the HPL402?

400 lb safe working load
Electric raising and lowering
Adjustable U-shaped base
Reverse-mounted actuator for additional knee clearance
Mechanical emergency lowering
Protective leg guards and caster bumpers
Optional patient scale
Compatible with the Hoyer Classic sling system

The HPL402 is a good fit when the portability of the Advance is not necessary but a powered Hoyer lift with a 400 lb capacity is preferred.

Hoyer HPL450 – Best Mid-Range Combination of Capacity & Flexibility

The Hoyer HPL450 increases the safe working load to 450 lb and adds configuration flexibility.

Joerns offers the HPL450 with either a powered base or a foot-operated manual base. It uses a 6-point cradle and includes two removable batteries with an off-board charger.

Why Choose the HPL450?

450 lb safe working load
Electric raising and lowering
Choice of powered or foot-operated base
6-point sling cradle
Two removable batteries
Off-board battery charger
Compact footprint for its capacity class
Suitable for both homecare and professional care environments

HPL450 Dimensions

Current Joerns specifications list the HPL450 at 25 inches wide with the legs closed and approximately 44.9 inches inside the legs when open.

The maximum height to the sling attachment point is approximately 73.5 inches, and the legs are approximately 4 inches high.

Always measure the actual transfer environment rather than relying on one published dimension when determining whether a lift will fit around a bed, chair, toilet, or doorway.

Hoyer Presence Pro 500 – Best for Higher Capacity & Professional Features

The Hoyer Presence Pro 500 provides the highest capacity and most advanced feature set of these four lifts.

The Presence has a 500 lb safe working load, lightweight aluminum frame, powered base, Smart Monitor technology, and a long lifting range.

Joerns specifically designed the Presence to handle transfers from the floor as well as transfers to higher surfaces.

Why Choose the Presence?

500 lb safe working load
Electric raising and lowering
Powered base
Smart Monitor technology
Lightweight engineered aluminum frame
Long lifting range
Floor-level lifting capability
Optional scale
Multiple sling attachment system options

Presence Lifting Range

Current Joerns specifications list a spreader-bar attachment range from approximately 16.9 inches at the minimum to 75.2 inches at the maximum.

The Presence's combination of low minimum attachment height and long lifting range helps make it suitable for floor recovery and transfers involving higher surfaces.

Which Hoyer Lift Has the Highest Capacity?

Among these four lifts, the Presence provides the highest safe working load:

Hoyer Advance-E – 341 lb
Hoyer HPL402 – 400 lb
Hoyer HPL450 – 450 lb
Hoyer Presence – 500 lb

Never select a lift based on patient weight alone. The patient's mobility, body dimensions, sling requirements, transfer surfaces, available space, and caregiver needs should also be considered.

Which Hoyer Lift Is Best for Travel or Storage?

The Advance-E is the clear choice among these four when frequent storage or transportation is a major requirement.

Its no-tools folding system is specifically designed to reduce the lift's storage footprint and make transportation easier.

The HPL402, HPL450, and Presence are better considered full-size mobile floor lifts rather than folding travel lifts.

Which Hoyer Lift Is Best for a 400 lb Patient?

A patient's actual weight must remain within the safe working load of the entire transfer system.

At or near 400 lb, the HPL402 reaches the upper limit of its 400 lb safe working load. The HPL450 and Presence provide higher rated capacities.

Capacity margin may be one factor in lift selection, but the final choice should also consider patient dimensions, sling requirements, transfer type, and the recommendations of the patient's care team.

Which Hoyer Lift Is Best for a 450 lb Patient?

The HPL450 has a maximum safe working load of 450 lb, while the Presence is rated to 500 lb.

For a patient at or near 450 lb, evaluate the complete transfer system carefully, including the safe working load of the sling and every other component.

Which Lift Has a Powered Base?

The Presence comes standard with a powered base.

The HPL450 is available with either a powered base or a foot-operated manual base, depending on configuration.

The HPL402 uses a manually adjustable U-base, and the Advance uses manually adjustable legs.

A powered base allows the caregiver to open and close the lift legs using powered controls rather than manually adjusting the base.

Which Lift Has the Best Battery Setup?

Battery-system design differs between the models.

The HPL450 is particularly useful in environments where reducing charging downtime is important because Joerns supplies it with two removable batteries and an off-board charger.

One battery can be installed on the lift while the other is available for charging.

Which Lift Is Best for Floor Transfers?

All four are full-body passive floor lifts capable of appropriate floor-level transfers when used according to the manufacturer's instructions and with a compatible sling.

The Presence is particularly notable for its long lifting range, while the Advance combines floor-transfer capability with a compact folding design.

Floor-transfer procedures, including caster and brake instructions, are model-specific. Always follow the current Joerns manual for the exact lift being used.

Sling Compatibility Is Different Between These Lifts

Do not assume that a sling used with one Hoyer lift will automatically fit another.

The HPL402 uses the Hoyer Classic sling system, with compatible options such as:

The Advance and HPL450 use compatible 6-point loop-style Hoyer sling systems.

The Presence can be configured with either a 6-point loop-style spreader bar or a 4-point positioning cradle for Hoyer Comfort slings with Securi3 clips.

Use our Hoyer Sling Compatibility Chart to verify attachment style and sling compatibility before ordering.

Advance-E vs HPL402

Choose the Advance-E when portability and folding storage are more important and the patient is within its 341 lb safe working load.

Choose the HPL402 when a traditional Hoyer homecare lift with a 400 lb capacity is preferred and folding is not required.

HPL402 vs HPL450

Choose the HPL402 for straightforward 400 lb electric homecare lifting with a traditional adjustable U-base.

Choose the HPL450 when the additional 450 lb capacity, dual-battery system, 6-point sling system, or choice of powered versus foot-operated base is more useful.

HPL450 vs Presence

Choose the HPL450 when a 450 lb mid-range lift provides sufficient capacity and you want the flexibility of powered or manual base configurations.

Choose the Presence when you need up to 500 lb capacity, a powered base, Smart Monitor technology, a longer lifting range, or the option of different sling attachment systems.

Which Hoyer Electric Lift Should You Choose?

Choose the Advance-E when portability, folding, and compact storage are the priorities.
Choose the HPL402 when you want straightforward electric homecare lifting with a 400 lb safe working load.
Choose the HPL450 when you want a 450 lb mid-range lift with dual batteries and a choice of powered or manual base.
Choose the Presence when you need up to 500 lb capacity, powered base operation, Smart Monitor technology, and a long professional lifting range.

The appropriate lift ultimately depends on the patient, transfer environment, sling requirements, caregiver needs, and the recommendations of the patient's care team.

Need Help Comparing Hoyer Electric Lifts?

Call 877-33-HOYER for help comparing specifications, sling compatibility, genuine accessories, and Joerns manufacturer resources for the Hoyer Advance-E 340, Hoyer HPL402, Hoyer HPL450, and Hoyer Presence Pro 500.
