The Hoyer HPL450 is a 450 lb electric full-body patient lift designed as a crossover option for both homecare and professional care environments. It combines a relatively compact footprint with electric lifting, a 6-point cradle, optional powered leg adjustment, an oversized push handle, and optional patient weighing.
If you are trying to determine whether the HPL450 will fit through your doorway, around your bed, under furniture, or into a specific transfer space, the dimensions below are the most important measurements to check.
Hoyer HPL450 Key Specifications
| Safe Working Load | 450 lb / 204 kg |
| Lift Type | Electric passive full-body floor lift |
| Maximum Overall Length | 51.1 in / 1300 mm |
| Maximum Overall Height | 79.8 in / 2027 mm |
| Minimum Overall Height | 54.3 in / 1380 mm |
| Spreader Bar Maximum Height | 73.5 in / 1867 mm |
| Spreader Bar Minimum Height | 22.2 in / 565 mm |
| Legs Open - External Width | 48.4 in / 1250 mm |
| Legs Open - Internal Width | 44.9 in / 1140 mm |
| Legs Closed - External Width | 25.0 in / 660 mm |
| Legs Closed - Internal Width | 22.8 in / 580 mm |
| Overall Height of Legs | 3.9 in / 100 mm |
| Powered Base Total Weight | 92.5 lb / 42.0 kg |
| Manual Base Total Weight | 92.0 lb / 41.7 kg |
| Power Pack Weight | 6.1 lb / 2.8 kg |
| Cradle | 6-point loop-style cradle |
| Base Options | Powered electric legs or foot-operated manual legs |
| Scale | Optional |
Joerns notes that published specifications may vary slightly due to manufacturing tolerances.
450 lb Safe Working Load
The Hoyer HPL450 has a safe working load of 450 lb / 204 kg.
The lift capacity does not automatically mean every sling, scale, cradle component, or accessory used with the lift is rated to 450 lb.
The complete transfer system is always limited by its lowest-rated component.
Powered or Manual Base Options
One of the HPL450's key advantages is that it is available with two different base configurations.
- HPL450-EL – powered electric leg adjustment
- HPL450-ML – foot-operated manual leg adjustment
The powered-base version allows the caregiver to open and close the lift legs electrically without bending, twisting, or manually forcing the base apart.
The manual-base version uses an ergonomically positioned foot pedal to adjust the leg width.
How Wide Is the HPL450?
With the legs closed, Joerns lists the HPL450 at approximately:
- 25.0 inches external width
- 22.8 inches internal width
With the legs fully open:
- 48.4 inches external width
- 44.9 inches internal width
These measurements are important when positioning the lift around wheelchairs, beds, recliners, commodes, and other furniture.
Will the HPL450 Fit Through a Doorway?
The HPL450 measures approximately 25 inches across the outside of the base with the legs closed.
Do not assume a doorway slightly wider than 25 inches automatically provides enough usable clearance.
Door trim, hinges, door swing, thresholds, caster position, approach angle, and nearby furniture can all reduce the actual opening.
Measure the narrowest clear point along the entire travel path before ordering.
How Long Is the HPL450?
Joerns lists the HPL450 at approximately 51.1 inches maximum overall length.
Overall length matters when planning turns in bedrooms, bathrooms, hallways, and other confined spaces.
Make sure there is enough room not only for the lift itself, but also for the caregiver to safely maneuver around the patient and destination surface.
How Tall Is the HPL450?
Joerns lists the maximum overall height at approximately 79.8 inches and the minimum overall height at approximately 54.3 inches.
Overall height should not be confused with the height of the sling attachment points.
The 6-point spreader bar has a published attachment range of approximately 22.2 inches to 73.5 inches.
HPL450 Lifting Range
The spreader bar can travel from approximately 22.2 inches at its lowest point to approximately 73.5 inches at its highest point.
This broad range allows the HPL450 to support many common full-body transfers involving beds, chairs, wheelchairs, and other seating surfaces.
Actual transfer geometry also depends on the sling, patient position, attachment-loop selection, and destination surface.
Can the HPL450 Lift From the Floor?
The HPL450 is a full-body passive floor lift with a low spreader-bar position of approximately 22.2 inches.
Appropriate floor transfers depend on the patient, compatible sling, available space, and the specific transfer procedure being used.
Always follow the current Joerns HPL450 manual and the patient's care plan for floor-level transfers.
Will the HPL450 Fit Under a Bed?
Joerns lists the HPL450 base legs at approximately 3.9 inches high.
Measure from the floor to the lowest obstruction beneath the bed or furniture.
Bed motors, frame crossbars, storage structures, casters, and other hardware can reduce usable clearance even when the visible side frame appears high enough.
Powered Base vs Manual Base
Both HPL450 versions provide the same 450 lb safe working load.
The powered-base version is useful when the caregiver wants electric opening and closing of the lift legs.
The foot-operated version avoids the additional powered leg mechanism while retaining electric raising and lowering of the patient.
The right configuration depends on the transfer environment, caregiver preference, and frequency of use.
HPL450 Weight
Joerns lists the HPL450 at approximately:
- 92.5 lb total with the powered base
- 92.0 lb total with the manual base
The removable power pack weighs approximately 6.1 lb.
The HPL450 is therefore significantly lighter than higher-capacity bariatric models such as the HPL700 and Calibre.
Oversized Ergonomic Push Handle
The HPL450 includes a large, ergonomically positioned push handle.
Joerns designed the handle to make the lift easier to maneuver while keeping the caregiver in an appropriate operating position.
Use the designated push handle when moving the lift rather than pulling or pushing on the boom, spreader bar, patient, or sling.
6-Point Sling Cradle
The HPL450 comes with a 6-point cradle designed for compatible Hoyer loop-style slings.
The six attachment points allow different loop positions to be used for patient positioning according to the sling instructions.
Do not use Securi3 clip-style slings with the standard HPL450 6-point cradle.
Compatible Hoyer Sling Options
Compatible Hoyer loop-style sling families may include:
- Hoyer Full Back Loop Sling
- Hoyer Access Padded Sling
- Hoyer Access Padded Sling with Head Support
- Hoyer Full Back Disposable Loop Sling
Sling selection should be based on patient measurements, transfer needs, support requirements, attachment style, and safe working load.
Use our Hoyer Sling Compatibility Chart before ordering.
Optional Patient Scale
Joerns offers an optional scale for the HPL450.
The scale includes a zeroing function so the patient can be weighed during the transfer process without including the sling weight in the final reading when used correctly.
Adding a scale does not increase the HPL450's 450 lb safe working load.
HPL450 Battery Setup
The HPL450 uses a removable rechargeable power pack.
Joerns supplies the HPL450 with two battery packs and an off-board charger, allowing one battery to remain available while the other is charging.
This can reduce downtime in environments where the lift is used several times throughout the day.
HPL450 vs HPL402
The Hoyer HPL402 has a 400 lb safe working load.
The HPL450 increases capacity to 450 lb and offers a choice between powered or foot-operated leg adjustment.
The HPL450 also provides a more modern crossover design for both homecare and professional environments.
HPL450 vs Advance-E 340
The Hoyer Advance-E 340 is designed around portability and folding storage.
The HPL450 provides a higher 450 lb safe working load but does not offer the same folding travel-oriented design.
Choose based on whether capacity or portability is the higher priority.
HPL450 vs Presence Pro 500
The Hoyer Presence Pro 500 provides a 500 lb safe working load, powered base, Smart Monitor technology, and a larger professional feature set.
The HPL450 is lighter and more compact while still offering 450 lb capacity.
The Presence may be more appropriate when the additional capacity and professional monitoring features are needed.
HPL450 vs HML400
The Hoyer HML400 is a manual hydraulic full-body lift.
The HPL450 provides powered raising and lowering and a higher safe working load.
The HML400 may appeal when a simpler non-battery lifting system is preferred.
Who Is the HPL450 Best For?
The HPL450 may be a strong option when:
- A 450 lb full-body passive lift is required.
- Electric lifting is preferred.
- A relatively compact footprint is important.
- The caregiver wants a choice between powered and manual base adjustment.
- A 6-point loop sling system is appropriate.
- An optional patient scale may be useful.
- The lift will be used in either homecare or a professional care environment.
Measure Before You Order
Before ordering the HPL450, measure:
- The narrowest doorway along the travel path
- Hallway width
- Available turning space
- Clearance under beds and chairs
- Width around wheelchairs and commodes
- Space required for the 48.4-inch fully open base
- Height and depth of common transfer surfaces
- Storage space when the lift is not in use
Also confirm whether the powered-base or foot-operated manual-base configuration is the better fit for the caregiver and transfer environment.
