The Hoyer Advance-E 340 is one of the most compact and portable full-body electric patient lifts in the Hoyer lineup. Its lightweight aluminum frame, no-tools folding design, low-profile legs, and broad lifting range make it especially useful in homes where storage space and maneuverability matter.
If you are trying to determine whether the Advance-E will fit through your doors, under your bed, around a wheelchair, or into your vehicle for transport, the measurements below are the most important ones to check.
Hoyer Advance-E 340 Specifications
| Safe Working Load | 341 lb / 155 kg |
| Maximum Overall Length | 51.2 in / 1300 mm |
| Minimum Overall Length | 49.2 in / 1250 mm |
| Maximum Overall Height | 73.2 in / 1860 mm |
| Minimum Overall Height | 53.5 in / 1360 mm |
| Spreader Bar Maximum Height | 66.5 in / 1690 mm |
| Spreader Bar Minimum Usable Height | 15.3 in / 390 mm |
| Legs Open - External Width | 42.5 in / 1080 mm |
| Legs Open - Internal Width | 39.3 in / 1000 mm |
| Legs Closed - External Width | 26.3 in / 670 mm |
| Legs Closed - Internal Width | 22.4 in / 570 mm |
| Overall Height of Legs | 4.5 in / 115 mm |
| Ground Clearance | 1.1 in / 30 mm |
| Turning Radius | 55.9 in / 1420 mm |
| Total Weight | Approximately 69.9 lb / 31.7 kg |
| Power Pack Weight | Approximately 6.2 lb / 2.8 kg |
Measurements are based on Joerns manufacturer specifications and may vary slightly due to manufacturing tolerances.
Folded Dimensions
One of the biggest advantages of the Hoyer Advance-E is its no-tools folding design.
| Folded Height | 17.7 in / 450 mm |
| Folded Depth | 46.5 in / 1180 mm |
| Folded Width | 21.7 in / 550 mm |
The Advance can stand upright in its folded configuration, making it easier to store in a closet, garage, storage room, or other compact space.
Will the Advance-E Fit Through a Doorway?
With the legs closed, the Advance measures approximately 26.3 inches across the outside of the base.
That number is useful when evaluating doorway clearance, but do not assume that a doorway measuring slightly more than 26.3 inches automatically provides enough room.
Hinges, trim, door swing, caster movement, approach angle, flooring transitions, and surrounding furniture can reduce usable clearance.
Measure the narrowest point of the actual travel path before ordering.
How Wide Is the Advance With the Legs Open?
With the legs fully open, Joerns lists the Advance at approximately 42.5 inches external width and 39.3 inches internal width.
The angled leg design allows the base to spread around larger chairs, commodes, and wheelchairs while still maintaining a relatively compact closed width for moving through the room.
Will the Advance Fit Under a Bed?
The Advance legs are approximately 4.5 inches high.
A bed, chair, recliner, or other piece of furniture must provide enough unobstructed clearance for the lift legs to travel beneath it.
Measure from the floor to the lowest structural component under the furniture, not just the visible side rail.
Adjustable-bed motors, crossbars, storage drawers, frame hardware, and other components can prevent the lift from sliding underneath even when the outer frame appears high enough.
Ground Clearance vs. Under-Bed Clearance
Ground clearance and leg height are different measurements.
Joerns lists approximately 1.1 inches of ground clearance beneath the Advance base, while the overall height of the lift legs is approximately 4.5 inches.
For determining whether the lift will travel beneath a bed or chair, the 4.5-inch leg height is the more relevant measurement.
Hoyer Advance Lifting Range
The electric Advance has a spreader-bar range from approximately 15.3 inches at its minimum usable height to 66.5 inches at its maximum height.
This wide lifting range allows the Advance to support appropriate transfers from floor level through beds, wheelchairs, commodes, and other seating surfaces.
Can the Hoyer Advance Lift Someone From the Floor?
Yes. Joerns specifically describes the Advance as capable of transfers from the floor through healthcare-bed height.
Floor-transfer suitability still depends on the patient, sling, surrounding space, and transfer plan.
Always use a compatible Hoyer sling and follow the current Joerns Advance user manual for the exact transfer being performed.
How Much Does the Advance-E Weigh?
Joerns lists the electric Advance at approximately 69.9 lb total.
The power pack accounts for approximately 6.2 lb of that weight.
The relatively low overall weight is one reason the Advance is often chosen when portability is important.
Can the Advance Be Transported in a Vehicle?
Yes. Joerns specifically designed the Advance so it can be transported in its folded configuration.
Its folded dimensions are approximately 17.7 inches high, 46.5 inches deep, and 21.7 inches wide.
Whether it will fit in a specific sedan, SUV, van, or trunk depends on the vehicle's cargo opening and interior dimensions.
Measure the vehicle opening as well as the available cargo area before assuming the lift will fit.
Car & Van Transfers
Joerns specifically highlights the Advance as useful for transfers involving cars and vans because of its folding design and angled legs.
Vehicle transfers require additional planning because door openings, seat height, dashboard position, vehicle floor height, sling selection, and available caregiver space can all affect the transfer.
Refer to the Joerns Advance car-transfer guidance and current user manual before performing a vehicle transfer.
Turning Radius & Home Maneuverability
Joerns lists the electric Advance turning radius at approximately 55.9 inches.
Turning radius is only one part of maneuverability. Tight bathrooms, narrow hallways, bedside furniture, door swing, and wheelchair placement may require additional room.
Create a clear travel path before every transfer and avoid assuming that a lift will turn comfortably simply because it fits through the doorway.
Swan-Neck / Angled Leg Design
The Advance uses Joerns' distinctive tapered or swan-neck-style leg design.
This allows the lift to approach large chairs, wheelchairs, bulky commodes, and other obstacles more closely than a traditional straight-leg design may allow.
The angled base is one of the Advance's primary advantages in residential environments where furniture positioning can make transfers difficult.
341 lb Safe Working Load
The Hoyer Advance has a safe working load of 341 lb (155 kg).
Never exceed the safe working load of the lift, sling, spreader bar, or any other component being used during the transfer.
The maximum usable capacity of the complete transfer system is determined by its lowest-rated component.
Advance-E Sling Attachment System
The standard Hoyer Advance uses a 6-point spreader bar for compatible loop-style Hoyer slings.
Common compatible sling families include Full Back, Quickfit, Access, and other Hoyer loop-style options appropriate for the patient and transfer.
Examples available from MyHoyerLift include:
- Hoyer Full Back Loop Sling
- Hoyer Access Padded Sling
- Hoyer Access Padded Sling with Head Support
- Hoyer Loop Style Full Back Disposable Sling
Use our Hoyer Sling Compatibility Chart to verify sling attachment type and compatibility before ordering.
Battery System
The electric Advance uses a 24V rechargeable sealed lead-acid battery system with a 3.2 Ah battery capacity.
The battery pack is removable from the lift for charging and service.
Follow the current Joerns charging instructions and do not continue operating the lift when a low-battery alarm is active.
Advance-E vs HPL402 for Home Use
The Hoyer Advance-E 340 is generally the stronger choice when folding storage, lower total weight, and portability are priorities.
The Hoyer HPL402 offers a higher 400 lb safe working load and a more traditional Hoyer Classic homecare design.
Advance-E vs HPL450
The Hoyer HPL450 provides a higher 450 lb safe working load and can be configured with a powered base.
The Advance is significantly more focused on portability and folding storage.
Who Is the Advance-E Best For?
The Hoyer Advance-E may be a strong option when:
- The patient is within the 341 lb safe working load.
- A full-body electric lift is required.
- Floor-transfer capability is important.
- Storage space is limited.
- The lift may need to be transported between locations.
- Access around chairs, commodes, and wheelchairs is important.
- A lighter lift is preferred over a larger professional model.
Measure Before You Order
Before ordering the Advance-E, measure:
- The narrowest doorway the lift must pass through
- Hallway width
- Available turning space
- Clearance under the bed or chair
- Width around the wheelchair or commode
- Available storage space
- Vehicle cargo opening and interior dimensions if transportation is planned
Comparing these measurements to the manufacturer's published dimensions can help identify potential fit problems before the lift arrives.
