Hoyer Stature Battery, Powered Base & Maintenance Guide

Aug 25, 2026

Proper battery care, powered-base inspection, cleaning, and preventive maintenance help keep the Hoyer Stature ready for regular use. Joerns provides specific charging, Smart Monitor, inspection, and service instructions for the Stature that should be followed instead of relying on generic patient-lift maintenance advice.

Hoyer Stature Battery System

The Hoyer Stature is supplied with two rechargeable battery packs and an off-board charger. This setup allows one battery to remain available for the lift while the second battery is charging.

Joerns recommends keeping the batteries fully charged whenever possible.

How Long Does the Stature Battery Take to Charge?

Joerns states that a full charge takes approximately four hours.

Charging is automatic:

Green light – mains power is on
Yellow light – the battery is charging
Yellow light off – the battery is fully charged

Joerns recommends charging the battery immediately when the lift is first received.

How to Charge the Hoyer Stature

Remove the battery pack from the lift by releasing the retaining latch.
Fit the battery pack securely onto the off-board charging unit.
Connect the charger to an appropriate electrical outlet.
Allow the battery to charge until the yellow charging light turns off.
Disconnect the charger from power.
Remove the battery from the charger.
Reinstall the battery on the Stature and make sure the latch clicks securely into place.

Can You Leave the Stature Battery Charging Overnight?

Yes. Joerns recommends keeping the batteries fully charged and states that a battery may be placed on charge whenever it is not in use.

The battery can also be charged every night if that is more convenient. The charger is designed to prevent the batteries from overcharging when left connected for an extended period.

Do Not Run the Battery Completely Flat

Joerns specifically instructs users not to run the Stature batteries completely flat.

When the Smart Monitor displays a half-empty battery symbol, the battery should be placed on charge as soon as possible.

If the audible low-battery warning sounds during operation, complete the lifting operation already in progress and place the battery on charge.

Battery Storage

Do not store the battery for long periods without regular charging.

Joerns also instructs users not to leave a battery pack connected to the charger when the charger itself is unplugged.

Before returning a stored lift to service, confirm that the battery is adequately charged and complete the normal pre-use inspection.

Important Charging Safety

Do not open the battery, charger, hand control, or control box.
Do not touch the battery or charger terminals.
Do not disconnect the charger by pulling on the cable.
Keep the charging lead positioned so it does not create a trip hazard.
Do not leave the charger powered with no battery connected.
Do not charge Stature batteries in a bathroom or shower room.

Hoyer Smart Monitor

The Stature can use Hoyer Smart Monitor technology to record and display service and usage information.

The Smart Monitor can track:

Total patient lift cycles
Total work performed by the actuator
Number of overload events
Number of days since the last service interval
Battery status
Service reminders

The information is available through the LCD display and helps caregivers and service personnel monitor lift use and preventive-maintenance needs.

Smart Monitor Battery Indicator

The Smart Monitor uses a three-step battery display:

Full battery symbol – battery is fully charged and ready for use
Half-empty battery symbol – battery should be charged soon
Empty battery symbol – battery should be charged immediately

Joerns recommends charging as soon as the half-empty symbol appears to help avoid permanent battery damage.

Smart Monitor Service Reminder

When the Stature reaches its service interval, the Smart Monitor displays a service symbol.

The system also produces an audible notification when the handset is used, indicating that preventive maintenance is recommended.

Service reminders should not be ignored. Arrange inspection and service before continuing long-term use.

Smart Monitor Overload Protection

If the Stature detects an attempted lift above its safe working load, the Smart Monitor records an overload event and stops the lifting function.

Lower the boom, remove the excess load, and complete the normal daily safety checks before the lift is returned to service.

Powered Base

The Hoyer Stature comes standard with electrically adjustable legs.

The caregiver can open or close the base using the hand control. This helps position the lift around armchairs, wheelchairs, beds, and other transfer surfaces while reducing the need for manual leg adjustment.

When the hand-control button is released, the legs remain locked in their selected position.

Using the Powered Base in Narrow Areas

Joerns recommends closing the legs when moving through narrow doorways and passages.

Once the lift is positioned in the transfer area, the powered base can be opened as needed to improve access and stability.

Powered Base Inspection

Test the legs through their full inward and outward range and confirm that they respond correctly to the hand control.

Inspect the powered-leg system for unusual noises, slow or irregular movement, damaged connections, or any condition that prevents the legs from opening and closing correctly.

Do not force the base against furniture, walls, or other obstructions.

Stature Caster & Brake Reminder

The Stature has two braked rear casters that may be used for parking.

During ordinary lifting, Joerns instructs that the casters should remain free and unbraked so the lift can move naturally toward its center of gravity.

Follow the current Stature manual for the specific transfer being performed. For floor lifting, Joerns provides separate model-specific wheel instructions.

Daily / Before-Use Stature Checklist

Joerns recommends completing routine checks before use.

Confirm the lift moves freely on its casters.
Check that the spreader bar or cradle moves freely and is securely attached.
Inspect sling hooks and attachment points for excessive wear.
Confirm the mast is securely connected to the chassis.
Test that the powered legs open and close correctly.
Operate the hand control and confirm the boom raises and lowers properly.
Confirm that no low-battery warning is present.
Test the emergency stop button.
Inspect the sling for fraying, tears, cuts, or other damage.
Check visible hardware for looseness or excessive wear.

Emergency Stop

The Stature has a red emergency stop button on the control box.

Pressing the button cuts power to the lift. Power is restored by twisting the emergency stop button counterclockwise and releasing it.

Caregivers should know the location and operation of the emergency stop before the lift is placed into regular service.

Redundant Raise & Lower Controls

The Stature control box includes redundant raise and lower buttons that can be used if the hand control fails.

On powered-leg configurations, redundant leg-open and leg-close controls are also available.

Mechanical Emergency Lowering

The Stature includes a mechanical emergency lowering system for use in a complete electrical failure.

The mechanism is located on the chassis and is operated using the manufacturer-specified tool procedure.

Staff responsible for the lift should understand the emergency-lowering method before the lift is placed into service.

Inspect the Spreader Bar or Positioning Cradle

The Stature may use either a 4-point Securi3 positioning cradle or a compatible 6-point loop-style spreader bar.

Inspect the installed attachment system for:

Freedom of rotation and movement
Wear at the central pivot
Secure attachment to the boom
Damaged hooks, clips, pins, or retaining components

Do not use the lift if the spreader bar, cradle, or attachment hardware appears damaged or excessively worn.

Inspect the Sling Before Every Transfer

Inspect the sling before each use for fraying, tears, cuts, damaged stitching, worn loops, damaged Securi3 clips, or other signs of deterioration.

Do not use a damaged sling.

Use our Hoyer Sling Compatibility Chart to confirm that the sling matches the Stature attachment system installed on the lift.

Mast & Boom Inspection

Check that the mast remains firmly connected to the chassis.

Inspect the boom-to-mast connection and confirm that there is only minimal movement at the attachment point.

Unusual looseness, structural damage, or excessive movement should be evaluated before the lift is returned to service.

Motor & Gearbox Inspection

Joerns states that the Stature motor gearbox normally requires no routine maintenance beyond checking correct operation and listening for unusual noise.

Unusual sounds, irregular boom movement, or inconsistent lifting should be evaluated by qualified service personnel.

Control Box & Handset Inspection

Check the function of the emergency stop button, hand-control socket, handset, redundant controls, and powered-leg controls.

Make sure the handset is fully connected to the controller and inspect visible cables and plugs for damage.

Caster Inspection

Confirm that all casters are firmly attached to the lift legs and rotate freely.

Hair, thread, debris, or other material around the caster can interfere with movement and should be removed.

Also verify that the base remains even and level with all four wheels contacting the floor.

Cleaning the Hoyer Stature

Joerns recommends cleaning the lift with ordinary soap and water and/or an appropriate hard-surface disinfectant.

Avoid harsh chemical cleaners and abrasive products because they can damage the lift's surface finish.

Avoid wetting the battery, control box, handset connections, powered-leg components, or other electrical parts.

Lubrication

Joerns includes lubrication of designated pivot joints as part of the annual maintenance schedule.

Maintenance points include:

Mast and boom connections
Pedal assembly where applicable
Spreader-bar joint when required
Other manufacturer-designated pivot points

Joerns specifies a silicone-based oil for appropriate pivot joints.

Lift Strap Inspection

The Stature lifting strap should be inspected at service intervals for signs of wear.

Joerns recommends inspection approximately every six months and immediate replacement by an authorized dealer or qualified service engineer if fraying, creasing, or similar damage is found.

500 lb Safe Working Load

The Hoyer Stature has a safe working load of 500 lb (227 kg).

Never exceed the safe working load of the lift, sling, positioning cradle, spreader bar, scale, or any other component in the transfer system.

Annual Service

Joerns recommends regular inspection plus an annual service and test.

Annual service should include inspection of:

Spreader bar or positioning cradle
Boom and mast
Motor gearbox
Control box or Smart Monitor
Battery system
Powered leg adjustment
Casters
Base and wheels
Slings
Quick-release pin
Hardware and fasteners
Lifting strap

Technical repair, structural work, electrical service, lifting-strap replacement, and formal load testing should be handled by qualified personnel or an authorized Hoyer service resource.

When to Stop Using the Stature

Remove the lift from service and arrange inspection if you notice:

A battery that will not maintain adequate charge
Repeated low-battery warnings after charging
A Smart Monitor overload or persistent service warning
Intermittent or unresponsive hand-control operation
Powered legs that do not open or close correctly
Unusual motor or gearbox noise
A damaged or insecure spreader bar or positioning cradle
Loose mast or boom components
Casters that do not roll or swivel freely
Visible wear or damage to the lifting strap
A damaged sling or sling attachment

Genuine Stature Cradles & Spreader Bars

MyHoyerLift carries genuine Joerns Stature attachment options, including:

Related Hoyer Patient Lifts

Lighter 500 lb professional option → Hoyer Presence Pro 500
Portable folding option → Hoyer Advance-E 340
700 lb bariatric option → Hoyer HPL700
850 lb bariatric option → Hoyer Calibre 850 lb Bariatric Lift

Need Help With Your Hoyer Stature?

Call 877-33-HOYER for help identifying genuine Hoyer batteries, chargers, Smart Monitor resources, powered-base components, cradles, spreader bars, replacement parts, accessories, or Joerns manufacturer documentation for your Hoyer Stature.
