The Hoyer Stature is a 500 lb professional passive patient lift designed around true vertical lifting. Its large lifting range, powered base, choice of clip-style or loop-style sling systems, and ability to lift from the floor or transfer to higher surfaces make it one of the most capable lifts in the Hoyer professional lineup.
The Stature is also a relatively large lift. Before ordering, it is important to compare its width, turning radius, leg height, lifting range, and sling configuration with the actual transfer environment.
Hoyer Stature Specifications
| Safe Working Load | 500 lb / 227 kg |
| Maximum Overall Length | 54.7 in / 1390 mm |
| Minimum Overall Length | 50.8 in / 1290 mm |
| Maximum Overall Height | 83.8 in / 2130 mm |
| Minimum Overall Height | 76.6 in / 1945 mm |
| Height at Maximum Reach | 77.8 in / 1975 mm |
| Maximum Reach | 24.6 in / 625 mm |
| Turning Radius | 61 in / 1550 mm |
| Legs Open - External Width | 53.5 in / 1360 mm |
| Legs Open - Internal Width | 48.4 in / 1230 mm |
| Legs Closed - External Width | 29.9 in / 760 mm |
| Legs Closed - Internal Width | 25.1 in / 640 mm |
| Overall Height of Legs | 4.3 in / 110 mm |
| Ground Clearance | 1.2 in / 30 mm |
| Front Casters | 4 in / 100 mm twin casters |
| Rear Casters | 4 in / 100 mm braked casters |
| Total Weight | Approximately 162 lb / 73.5 kg |
| Power Pack Weight | Approximately 6.6 lb / 3 kg |
Joerns notes that manufacturing tolerances apply to published dimensions. Always confirm the configuration of the specific Stature being used.
What Is True Vertical Lifting?
True vertical lifting is one of the defining features of the Hoyer Stature.
Instead of relying primarily on a broad arcing motion as the boom raises, the Stature is designed to provide a more vertical lifting path.
This geometry is particularly useful in demanding transfer situations where positioning over beds, chairs, treatment surfaces, or other destinations is important.
500 lb Safe Working Load
The Hoyer Stature has a safe working load of 500 lb (227 kg).
The lift's 500 lb rating does not automatically mean every sling, cradle, spreader bar, scale, or accessory attached to it is rated to the same capacity.
The maximum usable capacity of the complete transfer system is always determined by its lowest-rated component.
Standard 4-Point Positioning Cradle
The standard Stature configuration uses a 4-point positioning cradle designed for compatible Hoyer Comfort slings with Securi3 clip attachments.
According to Joerns, the standard 4-point positioning cradle has a usable attachment range of:
- Minimum usable height: 15.4 inches
- Maximum height: 61 inches
This low minimum attachment height helps the Stature perform appropriate floor-level transfers.
Optional 6-Point Spreader Bar
The Stature can also be configured with a 6-point spreader bar for compatible Hoyer loop-style slings.
With the 6-point spreader bar installed, Joerns lists:
- Minimum usable attachment height: 26.6 inches
- Maximum attachment height: 77.7 inches
The 6-point system therefore provides a substantially higher maximum attachment point than the standard 4-point positioning cradle.
4-Point vs. 6-Point Stature Lifting Range
| Configuration | Minimum Usable Height | Maximum Height |
| 4-Point Positioning Cradle | 15.4 in | 61 in |
| 6-Point Spreader Bar | 26.6 in | 77.7 in |
This difference is important when choosing the Stature configuration. The attachment system affects both sling compatibility and usable lifting geometry.
Can the Hoyer Stature Lift Someone From the Floor?
Yes. Joerns specifically identifies the Stature as capable of lifting residents from the floor.
Floor-transfer procedures should follow the current Stature user manual and use a sling and attachment system appropriate for the patient.
Joerns specifically instructs caregivers to lock the Stature's wheels when lifting a patient from the floor.
This floor-lift instruction should not be treated as a universal brake rule for every Hoyer lift or every transfer.
Can the Stature Transfer to High Surfaces?
Yes. Joerns designed the Stature to accommodate transfers to higher surfaces as well as floor-level lifting.
Its maximum overall height is approximately 83.8 inches, and the optional 6-point spreader bar reaches approximately 77.7 inches at its highest attachment position.
The actual usable transfer height depends on the installed cradle or spreader bar, sling, patient position, and destination surface.
How Wide Is the Hoyer Stature?
With the powered legs fully closed, the Stature measures approximately 29.9 inches across the outside of the base.
With the legs fully open, external width increases to approximately 53.5 inches.
Internal width with the legs open is approximately 48.4 inches.
The large open base provides useful positioning space but also means the Stature requires more room than many smaller homecare lifts.
Will the Hoyer Stature Fit Through a Doorway?
The published closed external width is approximately 29.9 inches.
Do not assume a nominal 30-inch doorway automatically provides enough usable clearance.
Door trim, hinges, door swing, caster orientation, approach angle, thresholds, and nearby furniture can reduce the actual opening.
Measure the narrowest clear opening along the entire travel path before ordering.
Will the Stature Fit Under a Bed?
The Stature's base legs are approximately 4.3 inches high.
Measure from the floor to the lowest obstruction beneath the bed or furniture.
Bed motors, crossbars, frame components, storage structures, and other hardware may reduce usable clearance even when the visible side of the bed appears high enough.
Ground Clearance
Joerns lists approximately 1.2 inches of ground clearance beneath the Stature.
Ground clearance and leg height are different measurements.
For determining whether the base can travel underneath furniture, the approximately 4.3-inch leg height is generally the more relevant measurement.
61-Inch Turning Radius
The Stature has a published turning radius of approximately 61 inches.
This matters when planning use in bedrooms, bathrooms, hallways, and other confined spaces.
A lift may fit through a doorway but still require considerably more room to turn and position around the patient and destination surface.
Powered Base Adjustment
The Stature comes with powered leg adjustment.
The caregiver can open and close the base using powered controls rather than manually spreading the legs.
Joerns designed this system to reduce the bending, twisting, and physical force associated with manually adjusting a large lift base.
Swan-Neck Leg Design
The Stature uses swan-neck-style legs designed to help the lift get closer to the resident and surrounding transfer surface.
This geometry can improve positioning around beds, wheelchairs, chairs, and other furniture while still providing the wide stance available from the powered base.
How Much Does the Hoyer Stature Weigh?
Joerns lists the complete Stature at approximately 162 lb (73.5 kg).
The mast, base, and boom assembly account for approximately 142 lb, while the removable power pack weighs approximately 6.6 lb.
The standard manual 4-point positioning cradle weighs approximately 13.2 lb.
Because the Stature is substantially heavier than portable homecare lifts such as the Advance-E, it should be viewed as a full-size professional mobile lift rather than a travel lift.
Optional Powered Positioning Cradle
Joerns offers an optional powered positioning cradle for the Stature.
The powered cradle allows the caregiver to adjust patient positioning while remaining close to the resident.
Joerns lists the powered 4-point positioning cradle at approximately 19.8 lb.
The powered cradle should be matched with compatible Hoyer Securi3 clip-style slings.
Optional Digital Scale
A digital patient scale is available for the Stature.
Joerns specifically notes that the scale option does not compromise the lift's available lifting height.
Adding a scale does not increase the 500 lb safe working load of the Stature.
Stature Sling Attachment Options
The Stature can support two distinct Hoyer sling attachment systems:
- 4-point positioning cradle for compatible Hoyer Comfort Securi3 clip-style slings
- 6-point spreader bar for compatible Hoyer loop-style slings
Loop and clip attachment systems are not interchangeable.
Always identify the cradle or spreader bar installed on the lift before ordering a sling.
Genuine Stature 4-Point Cradle Options
MyHoyerLift carries the Joerns Hoyer HOY-4PTSB 4-Point Adaptive Positioning Cradle for compatible Hoyer professional lifts.
A powered wide positioning option is also available: Joerns Hoyer HOY-4PT-APC-W Powered 4-Point Positioning Cradle.
Genuine Stature 6-Point Spreader Bar Options
For loop-style sling configurations, compatible options include the Joerns Hoyer HOY-6PTSB 6-Point Spreader Bar and the Joerns Hoyer 0Y0189 6-Point Spreader Bar Assembly.
Compatible Loop-Style Slings
When the Stature is equipped with a compatible 6-point spreader bar, available Hoyer loop-style options include:
- Hoyer Full Back Loop Sling
- Hoyer Access Padded Sling
- Hoyer Access Padded Sling with Head Support
- Hoyer Full Back Disposable Loop Sling
Compatible Securi3 Clip-Style Slings
When the Stature is equipped with a 4-point positioning cradle, use compatible Hoyer Comfort slings with Securi3 clips.
One option available from MyHoyerLift is the Hoyer Comfort Access Clip Style Toileting Sling.
Sling selection should be based on patient assessment, sizing, positioning needs, transfer type, attachment system, and the sling's safe working load.
Stature vs Presence Pro 500
The Hoyer Presence Pro 500 and Stature both have 500 lb safe working loads and powered bases.
The Presence is lighter and more compact, while the Stature is designed around true vertical lifting and a larger professional transfer geometry.
The Stature has an open external base width of approximately 53.5 inches compared with approximately 45 inches for the Presence, so available room can be an important deciding factor.
Stature vs Advance-E 340
The Hoyer Advance-E 340 is designed around portability and compact folding storage.
The Stature provides a higher 500 lb safe working load, powered base, true vertical lifting, and professional cradle options, but it is considerably larger and heavier.
Stature vs Calibre 850
The Hoyer Calibre 850 is the higher-capacity bariatric option.
Choose the Stature when 500 lb capacity is sufficient and true vertical lifting is a priority.
Consider the Calibre when the patient requires bariatric capacity beyond the Stature's 500 lb safe working load.
Who Is the Hoyer Stature Best For?
The Stature may be a strong option when:
- A 500 lb professional passive patient lift is required.
- True vertical lifting is important.
- Floor-level transfers are required.
- Transfers to higher surfaces are common.
- Powered leg adjustment is preferred.
- A 4-point Securi3 positioning cradle is desired.
- A 6-point loop-style sling system may be required.
- An optional powered positioning cradle would be useful.
- A patient scale may be needed.
- The care environment has enough room for the Stature's larger footprint.
Measure Before You Order
Before ordering a Hoyer Stature, measure:
- The narrowest doorway along the travel path
- Hallway width
- Available turning space
- Clearance beneath beds and furniture
- Width around wheelchairs, commodes, and chairs
- Space required for the 53.5-inch fully open base
- Height and depth of the transfer surfaces
- Storage space when the lift is not in use
Also determine whether the Stature will use the standard 4-point positioning cradle or an optional 6-point spreader bar, because that choice changes both sling compatibility and lifting range.
Need Help Confirming the Stature Will Fit?
Call 877-33-HOYER for help comparing dimensions, sling systems, 4-point cradles, 6-point spreader bars, scale options, genuine accessories, or Joerns manufacturer resources for the Hoyer Stature.
